HeartStart FRx

AED

Find similar products

The Philips HeartStart FRx defibrillator features intuitive, step-by-step voice instructions, including CPR guidance, and an audible metronome to help guide basic life support (BLS) responders while treating a suspected sudden cardiac arrest (SCA) Pre-connected SMART Pads II can be used for both adults and children. Rugged, lightweight and reliable, it can withstand rough handling and extreme temperatures. When every minute counts, Philips HeartStart FRx is the partner by your side. Side by side. Step by step.

Contact & support
Features
Patented technology. Proven therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.
Easy as 1–2–3

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.
Works where you need it

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).
Simplified maintenance

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.
  • Patented technology. Proven therapy.
  • Easy as 1–2–3
  • Works where you need it
  • Simplified maintenance
See all features
Patented technology. Proven therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.

Patented technology. Proven therapy.

Real-time, step-by-step voice commands paced to your actions, and an audible metronome and CPR guidance assist the responder. When treating an infant or child, simply insert the optional infant/child key and the FRx adjusts instructions and therapy.
Easy as 1–2–3

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.

Easy as 1–2–3

Patented Quick Shock feature allows the FRx to typically deliver a shock within 8 seconds after CPR.1 Studies show that minimizing time to shock after CPR may improve survival..2-5 1. Press the green On/Off button, which activates voice instruction and visual icons. 2. Place the pads on the patient as directed. 3. When advised by the device, press the orange Shock button.
Works where you need it

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).

Designed to work where you need it

Lightweight, rugged and reliable, the Philips HeartStart FRx defibrillator can withstand rough handling, extreme temperatures, and dusty or wet surfaces. Designed for use in harsh settings, it can withstand up to 500 kg (1,100 lbs) and drops from 1.2 m (4 ft).
Simplified maintenance

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.

Simplified maintenance

Pre-connected SMART Pads II can be used for both adults and children. Once installed and activated, the FRx is easy to maintain. It performs a series of automatic self-tests, daily, weekly, and monthly to check pad readiness and verify functionality and calibration of circuits and systems. It can last up to four years between battery replacements.

Documentation

Application notes (1)

Application notes

Brochure (3)

Brochure

Instructions for use (1)

Instructions for use

Customer story (2)

Customer story

Product overview (3)

Product overview

Product news (2)

Product news

Flyers (2)

Flyers

Application notes (1)

Application notes

Brochure (3)

Brochure

See all documentation

Application notes (1)

Application notes

Brochure (3)

Brochure

Instructions for use (1)

Instructions for use

Customer story (2)

Customer story

Product overview (3)

Product overview

Product news (2)

Product news

Flyers (2)

Flyers

Specifications

Product specifications
Product specifications
Model Number
  • 861304
Waveform
  • Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
Battery
  • Typically 4 years when stored and maintained according to directions provided in Owner’s Manual. Standby life (after insertion):
Therapy
  • Adult defibrillation peak current: 32A (150J nominal) into a 50 ohm load. Pediatric defibrillation (with optional Infant/Child Key installed): 19A (50J nominal) into a 50 ohm load.
Protocol
  • Protocol Device follows preconfigured settings. Defibrillation and CPR protocol can be customized using HeartStart Event Review or HeartStart Configure software.
Quick Shock
  • Able to deliver a shock after the end of a CPR interval, typically in eight seconds.
Physical requirements
Physical requirements
Size
  • 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight
  • With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
Environmental
Environmental
Temperature
  • Operating/Standby:32° - 122° F (0° - 50° C)
EMI (Radiated/Immunity)
  • CISPR II Group I Class B, IEC 61000-4-3, and IEC 61000-4-8
Sealing
  • Waterjet proof IPX5 per IEC60529 Dust protected IPX5 per IEC60529
Altitude
  • 0 to 15,000 feet
Aircraft
  • Device: RTCA/DO-160D;1997
Crush
  • 500 pounds
Vibration
  • Operating: meets MILSTD 810F Fig.514.5C-17, random Standby: meets MILSTD 810F Fig.514.5C-18,swept sine.
Product specifications
Product specifications
Model Number
  • 861304
Waveform
  • Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
Physical requirements
Physical requirements
Size
  • 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight
  • With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
See all specifications
Product specifications
Product specifications
Model Number
  • 861304
Waveform
  • Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
Battery
  • Typically 4 years when stored and maintained according to directions provided in Owner’s Manual. Standby life (after insertion):
Therapy
  • Adult defibrillation peak current: 32A (150J nominal) into a 50 ohm load. Pediatric defibrillation (with optional Infant/Child Key installed): 19A (50J nominal) into a 50 ohm load.
Protocol
  • Protocol Device follows preconfigured settings. Defibrillation and CPR protocol can be customized using HeartStart Event Review or HeartStart Configure software.
Quick Shock
  • Able to deliver a shock after the end of a CPR interval, typically in eight seconds.
Physical requirements
Physical requirements
Size
  • 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight
  • With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
Environmental
Environmental
Temperature
  • Operating/Standby:32° - 122° F (0° - 50° C)
EMI (Radiated/Immunity)
  • CISPR II Group I Class B, IEC 61000-4-3, and IEC 61000-4-8
Sealing
  • Waterjet proof IPX5 per IEC60529 Dust protected IPX5 per IEC60529
Altitude
  • 0 to 15,000 feet
Aircraft
  • Device: RTCA/DO-160D;1997
Crush
  • 500 pounds
Vibration
  • Operating: meets MILSTD 810F Fig.514.5C-17, random Standby: meets MILSTD 810F Fig.514.5C-18,swept sine.
  • 1. Nichol, G., Sayre, M. R., Guerra, F., & Poole, J. (2017). Defibrillation for Ventricular Fibrillation: A Shocking Update., 70(12), 1496-1509. Journal American College of Cardiology doi:10.1016/j. jacc.2017.07.778
  • 2. Eftestol, T., Sunde, K., & Steen, P. A. (2002). Effects of interrupting precordial compressions on the calculated probability of defibrillation success during out-of-hospital cardiac arrest. Circulation, 105(19), 2270-2273. doi:10.1161/01. CIR.0000133323.15565.75
  • 3. Yu, T., Weil, M. H., Tang, W., Sun, S., Klouche, K., Povoas, H., & Bisera, J. (2002). Adverse outcomes of interrupted precordial compression during automated defibrillation. Circulation, 106(3), 368-372. doi:10.1161/01.CIR.0000021429.22005.2E
  • 4. Snyder, D., & Morgan, C. (2004). Wide variation in cardiopulmonary resuscitation interruption intervals among commercially available automated external defibrillators may affect survival despite high defibrillation efficacy. Critical Care Medicine, 32(9 Suppl), S421-S424. doi:10.1097/01.CCM.0000134265.35871.2B
  • 5. Edelson, D. P., Abella, B. S., Kramer-Johansen, J., Wik, L., Myklebust, H., Barry, A. M., . . . Becker, L. B. (2006). Effects of compression depth and pre-shock pauses predict defibrillation failure during cardiac arrest. Resuscitation, 71(2), 137-145.
